Spezifikation der PE-Beschichtung Aluminium-Verbundplatte
| Breite: | Standard 1220mm & 1250mm, Optionen 900mm, 1500mm, 2000mm, |
| Länge: | Standard 2440mm, Optionen: 3050mm, 5000mm, 5800mm, bis zu 11500mm |
| Plattenstärke: | 3mm & 4mm, Optionen: 1 mm, 2 mm, 5 mm, 6 mm, 7 mm, 8 mm, usw. |
| Alu Spulendicke: | 0,5 mm, 0,45 mm, 0,4 mm, 0,35 mm, 0,3 mm, 0,25 mm, 0,21 mm, 0,10 mm, etc |
| Kernmaterial: | Normaler Kern / Unbreakable Kern / Recycle-Core / Core-Feuerbeständige |
| Beschichtung: | PE,PVDF, FEVE,Nano,Epoxy coating,etc |
| Farbe: | Uni-, Metallic-, hochglänzend, Digitaldruck, Spiegel, Steinoptik, Holz-Optik, gebürstet, usw. |
| Gewicht: | 5-6.5kg / Quadratmeter, basierend auf 4 mm Dicke |
| Funktion: | Fireproof, Mould Proof, self-cleaning, Anti-Static, Antibacterial,etc |
The color card is partially displayed, and the color can be customized as needed.
- Exterior Wall Cladding & Facades
- Advertising Signage & Billboards
- Interior Decoration (Partitions, Ceilings, Shopfitting)
- Exhibition Stands & Display Panels
| Product Name | China aluminum composite panel |
| Brand Name | Aludream |
| Model Number | A-50024 |
| Usage | Building Wall Facade |
| Function | B1/A2 fireproof, water-proof, self-cleaning, weather-resistance |
| Surface treatment | PVDF painting/ Powder coating/ Stone and wood grain/ Mirror surface/ Wire surface |
| Color | Any RAL Color or Customized color |
| Coating Brand | Chinese famous brands, or international brands PPG/DNT/AKZO/NIPPON, etc |
| Material | Aluminum Alloy AA1006 H14, 1100 H24 , 3003, 5032, 6063 etc. |
| thickness | 3.0mm – 6.0mm |
| Standard size | 4*8 ft/ 1220*2440 mm |
| Maximum size | 5*17 ft / 1600*5100mm |
| Anwendung | Building Exterior Wall Facade |
| Production capacity | 20000 Square Meters/per month |
| Delivery time | 15-40days |
| After-sale Service | Online technical support |
| Place of Origin | Shanghai, China |
20 years warranty
Provide long-term effective warranty service and after-sales service.
Low minimum order quantity
Minimum order quantity, can be negotiated according to actual needs.
Customizable solutions
Protective film, color, size, thickness and other parameters can be customized.
Support Door-To-Door service
Compared to other suppliers, we provide door-to-door service,More competitive price
Free samples sent
We provide free sample service, you only need to bear the shipping cost.
